产品参数
| 产品型号 | 额定功率 | 额定扭矩 | 额定转速 | 额定电流 | 峰值扭矩 | 峰值转动 | 峰值电流 |
| (w) | (Nm) | (rpm) | (Arms) | (Nm) | (rpm) | (Arms) | |
| 48VDC电压 | |||||||
| EXP13020S | 2000 | 7.7 | 2500 | 52 | 15.4 | 2800 | 104 |
| EXP13026S | 2600 | 10 | 2500 | 76 | 20 | 2800 | 152 |
| EXP13026S | 3800 | 15 | 2500 | 81 | 22.5 | 2650 | 122 |
| 72VDC电压 | |||||||
| EXP13020Q | 2000 | 7.7 | 2500 | 28 | 15.4 | 3000 | 56 |
| EXP13026Q | 2600 | 10 | 2500 | 38 | 20 | 2800 | 76 |
| EXP13026Q | 3800 | 15 | 2500 | 52 | 30 | 2800 | 104 |
| 220VAC电压 | |||||||
| EXP13020L | 2000 | 7.7 | 2500 | 7.5 | 22 | 2800 | 15.3 |
| EXP13026L | 2600 | 10 | 2500 | 10 | 25 | 3000 | 19.4 |
| EXP13038L | 3800 | 15 | 2500 | 13.5 | 30 | 3000 | 27.7 |
| 380VAC电压 | |||||||
| EXP13020H | 2000 | 2.39 | 3000 | 1.6 | 7.1 | 4000 | 4.8 |
| EXP13026H | 2600 | 3.5 | 3000 | 3 | 10.5 | 4500 | 9 |
| EXP13038H | 3800 | 15 | 2500 | 7.4 | 30 | 3000 | 14.8 |
