产品参数
| 产品型号 | 额定功率 | 额定扭矩 | 额定转速 | 额定电流 | 峰值扭矩 | 峰值转动 | 峰值电流 |
| (w) | (Nm) | (rpm) | (Arms) | (Nm) | (rpm) | (Arms) | |
| 48VDC电压 | |||||||
| EXP9008S | 750 | 2.39 | 3000 | 19.5 | 4.78 | 4000 | 39 |
| EXP9010S | 1000 | 3.5 | 3000 | 26 | 7 | 4000 | 52 |
| 72VDC电压 | |||||||
| EXP9008Q | 750 | 2.39 | 3000 | 10.5 | 4.78 | 3500 | 21 |
| EXP9010Q | 1000 | 3.5 | 3000 | 16 | 7 | 3500 | 32 |
| 220VAC电压 | |||||||
| EXP9008L | 750 | 2.39 | 3000 | 3 | 7.1 | 3500 | 9 |
| EXP9010L | 1000 | 3.5 | 3000 | 4.5 | 10.5 | 3500 | 13.5 |
| 380VAC电压 | |||||||
| EXP9008H | 750 | 2.39 | 3000 | 1.6 | 7.1 | 4000 | 4.8 |
| EXP9010H | 1000 | 3.5 | 3000 | 3 | 10.5 | 4500 | 9 |
